Float switch

Scope of delivery
<ul>
<li>Float switch</li>
<li>Counterweight with ring</li>
<li>Cable 1.75 cm - black</li>
<li>Operating Instructions Water Sensors | Float Switches | Accessories</li>
</ul>
&nbsp;
<h2 data-start="185" data-end="237">⚙️ Float switch (accessory for water detectors)</h2>
<p data-start="238" data-end="335"><strong data-start="238" data-end="335">Robust level control for pumps, valves and controls – even with contaminated water</strong></p>

<hr data-start="337" data-end="340" />

<h3 data-start="342" data-end="395">💪 Reliable even under the toughest conditions</h3>
<p data-start="396" data-end="684">The classic SCHABUS float switch is the ideal solution for the automatic control of pumps or valves – especially in environments with contaminated or murky water. Its robust plastic housing is IP68-rated and designed for continuous operation.</p>

<hr data-start="686" data-end="689" />

<h3 data-start="691" data-end="737">🔌 Easy connection, flexible installation</h3>
<ul data-start="738" data-end="986">
<li data-start="738" data-end="764">
<p data-start="740" data-end="764"><strong data-start="740" data-end="755">Cable length:</strong> 1.75 m</p>
</li>
<li data-start="765" data-end="801">
<p data-start="767" data-end="801"><strong data-start="767" data-end="789">Connection voltage:</strong> up to 250 V</p>
</li>
<li data-start="802" data-end="837">
<p data-start="804" data-end="837"><strong data-start="804" data-end="823">Switching capacity:</strong> up to 1,000 W</p>
</li>
<li data-start="838" data-end="924">
<p data-start="840" data-end="924"><strong data-start="840" data-end="858">Switching principle:</strong> mechanical – reacts to rising or falling water level</p>
</li>
<li data-start="925" data-end="986">
<p data-start="927" data-end="986"><strong data-start="927" data-end="939">Mounting:</strong> e.g. with counterweight or attached to the cable</p>
</li>
</ul>

<hr data-start="988" data-end="991" />

<h3 data-start="993" data-end="1024">✅ VDE-tested & durable</h3>
<ul data-start="1025" data-end="1158">
<li data-start="1025" data-end="1071">
<p data-start="1027" data-end="1071"><strong data-start="1027" data-end="1044">Switching cycles:</strong> approx. 50,000 (VDE-tested)</p>
</li>
<li data-start="1072" data-end="1117">
<p data-start="1074" data-end="1117"><strong data-start="1074" data-end="1097">Operating temperature:</strong> –20 °C to +50 °C</p>
</li>
<li data-start="1118" data-end="1158">
<p data-start="1120" data-end="1158"><strong data-start="1120" data-end="1158">Ready for use in private and commercial applications</strong></p>
</li>
</ul>

<hr data-start="1160" data-end="1163" />

<h3 data-start="1165" data-end="1198">🌊 Typical areas of application</h3>
<ul data-start="1199" data-end="1314">
<li data-start="1199" data-end="1227">
<p data-start="1201" data-end="1227">Rainwater and wastewater tanks</p>
</li>
<li data-start="1228" data-end="1253">
<p data-start="1230" data-end="1253">Cisterns and wells</p>
</li>
<li data-start="1254" data-end="1272">
<p data-start="1256" data-end="1272">Pump shafts</p>
</li>
<li data-start="1273" data-end="1314">
<p data-start="1275" data-end="1314">Container with heavily contaminated water</p>
</li>
</ul>

<hr data-start="1316" data-end="1319" />

<h3 data-start="1321" data-end="1357">🛠️ Special solutions on request</h3>
<p data-start="1358" data-end="1451">Special cables or specific configurations are available upon request. Contact us!</p>
&nbsp;

<img class="alignnone size-full wp-image-18518" src="https://www.elektrotechnik-schabus.de/wp-content/uploads/2023/09/200983-Masse-230V-Schwimmerschalter.jpg" alt="" width="300" height="300" /> <img class="alignnone size-full wp-image-18519" src="https://www.elektrotechnik-schabus.de/wp-content/uploads/2023/09/200983-MZ-230V-Schwimmerschalter.jpg" alt="" width="300" height="300" />
