Scope of delivery
Exhaust systems such as bathroom fans or extractor hoods create negative pressure in the room if there is insufficient fresh air flow. If a fireplace (e.g., gas boiler, central heating boiler) is located in the same room, there is a risk that toxic exhaust gases – such as carbon monoxide – will be sucked back into the living space from the chimney.
The KGS 116 exhaust air control system prevents precisely this risk: It only allows the exhaust air system to operate when the fireplace is not in use.
The control unit is permanently connected to the potential-free contact of the gas boiler (normally open). As soon as the boiler ignites, the KGS 116 detects the changed contact state and interrupts the power supply to the connected exhaust air system.
If the gas boiler is deactivated again, the control system automatically releases the exhaust air system again.
Safety principle: Exhaust air is only permitted if no exhaust gases can be produced.
The KGS 116 cable gas boiler control system queries the potential-free normally open contact of a gas boiler and converts the gas boiler's state change into a switching of the potential-free changeover relay. This system can be used to turn off a bathroom fan, for example, when the gas boiler is ignited.
The KGS 116 control unit is connected to the potential-free contact (normally open) of the gas boiler with a cable. As soon as combustion starts, the exhaust air system (e.g., bathroom fan) is switched off. The control unit can be installed surface-mounted or flush-mounted in a distribution box, switch, or socket with a minimum diameter of 60 mm. The side mounting tabs on the control unit can be removed if necessary.
WEEE NO.: DE91394868
| Operating voltage | 230 V AC / 50 Hz |
|---|---|
| Switching capacity | 3500 VA (2300 W), 16 A (10 A) |
| Functional area | -15°C / +40°C |
| Protection class | IP20 |
| Line | 4 meters, special length on request |
| Control voltage | 18 V |
