Item number: 201753
Delivery time: 2-3 working days
View full details
The specially adapted Certotec ATW 519 KDS was developed by Elektrotechnik Schabus specifically for use with the KDS 110 and KDS 116 cable exhaust air controls . Its special feature: The integrated 10 kΩ fuse resistor makes it possible to reliably distinguish a closed contact (furnace running) from a cable break or an open contact (furnace off | window open) . This feature is essential for KDS systems, as the resistance allows them to distinguish between deliberate operation and errors.
This eliminates the need to open a window to operate the extractor hood—if the stove isn't running anyway, the control system automatically detects this. A clever solution for households where the stove is only used occasionally.
Exhaust air release without opening the window : KDS automatically detects that the stove is off
Thermal switch in set KDT 210 : For temperature monitoring in complete systems
Alternative to radio transmission : Also available as radio version FTX 519
The ATW 519 KDS also has a switching point of approximately 40 °C , is TÜV-tested according to DIN EN 14597 , and offers maximum operational reliability thanks to its intrinsically safe, maintenance-free design . Its electrical feature is the integrated 10 kΩ resistor , which serves as a cable break detector. This function is intended exclusively for KDS systems; with other control systems, the resistor may interfere with operation.
This temperature monitor is also suitable for exhaust gas temperatures up to 500°C . The switch head and the pre-assembled 2 m silicone cable can withstand temperatures up to 180°C. For longer distances, the connecting cable can be extended with a 2-wire cable outside of the heat source.
It is mounted directly on the stovepipe – ideally approximately 80 cm from the top edge of the stove . This ensures that a switching signal is only sent to the KDS system when the stove is actually in operation. It is connected in series with the window contact – entirely in accordance with the KDS system logic.
WEEE NO.: DE91394868
| TÜV tested | according to DIN EN 14597, TÜV tested |
|---|---|
| Brand | Cetrotec |
| Limit range | 40°C, factory set |
| Line | 2 m (4-wire) | Silicone | max. 180°C |
| Medium | Air or smoke gas |
| Switching difference | approx. 15 K |
| Switching accuracy | +/- 7K |
| Temperature | 0-500 °C medium temperature, max. 180 °C cable temperature |
| Time | < 45 seconds response time |
